Designers of space-constrained designs can now significantly increase runtime with the MAX20361 single-/multi-cell solar harvester with maximum power point tracking (MPPT) from Maxim Integrated Products, Inc. The industry’s smallest solar harvesting solution is ideal for space-constrained applications such as wearables and emerging internet of things (IoT) applications.

Designers are often challenged with the tradeoff between small size and long runtime for wearable and IoT applications. By enabling solar charging in these highly space-constrained products, the MAX20361 can extend the runtime of those devices by providing a supplemental power source. This solar harvester reduces solution size by at least half compared to the closest competitor. In addition, the MAX20361 increases harvested energy with up to 5 percent better boost efficiency than the closest competitor, coupled with an adaptive MPPT approach which can improve the overall system-level efficiency even further.

Smallest Size: Industry’s smallest solar harvesting solution due to reduced component size and smaller, fewer external components; at least 50 percent smaller solution size compared to the closest competitor

Higher Efficiency: Increased boost efficiency maximizes harvested energy with up to 5 percent better boost efficiency than the closest competitor; additional harvesting gains can be achieved through adaptive MPPT features coupled with the unique integrated harvesting gauge for real-time indications of efficiency to optimize performance

The MAX20361 is available at Maxim Integrated’s website for $2.64 (1000-up, FOB USA); also available from authorized distributors. The MAX20361EVKIT# evaluation kit is available for $57
