Acromag expands their offering of AcroPack rugged I/O modules based on the PCI Express mini card standard with two new MIL-STD-1553 communication modules. The AP571 provides single function MIL-STD-1553 communication and the AP572 provides full multi-function databus communication.
Both models provide one dual redundant channel with four open/ground avionics level discrete I/O signals in addition to IRIG-B I/O and Trigger I/O. A high performance SoC architecture features dual-core RISC processors tightly coupled to large programmable logic for host CPU offload and real-time functionality. With 128MB global RAM on-board for data scheduling and buffering, the module can operate dependably at full bus rates. Designed for COTS applications, these mPCIe mezzanine modules deliver a SWaP-optimized solution for avionics test, simulation, and monitoring applications. A variety of carrier cards are available to host a mix of up to four AcroPack I/O modules on PCI Express, VPX or XMC computer platforms.
AcroPack mezzanine modules improve on the mini PCI Express architecture by adding a down-facing 100-pin connector that securely routes the I/O through a carrier card without any loose internal cabling. Carrier cards in PCIe, VPX, and XMC formats let you combine up to four I/O function modules from more than 25 available models in a single computer slot. Software tools support embedded applications running on Linux®, Windows®, or VxWorks® operating systems. www.acromag.com.
