ASRock Industrial Computer brings the new Mini PCs and motherboards powered by Intel Atom x6000E Series, Intel Pentium, and Celeron N and J Series Processors (Elkhart Lake), with available selections- NUC 6000 BOX Series, iBOX 6000 Series, and NUC 6000 Motherboard Series. Featuring advanced CPU and graphics performance with integrated IoT features and longevity support, the new Series provides rich industrial-centric I/Os, including dual Gigabit Ethernet LAN ports, dual displays up to 4K at 60Hz, and dual storages with SATA 3.0 and M.2 (Key M, 2242/2260/2280) to accelerate system integration development for the next generation of IoT applications in the home, business, retail, banking, hospitality, manufacturing, transportation, healthcare, and more.
The NUC 6000 BOX Series Mini PC includes model NUC BOX-J6412, featuring Intel Celeron Processor J6412 (Elkhart Lake) and an optional model provided upon customer request- NUC BOX-J6426, based on Intel Pentium Processor J6426. The Series is compact- 110.0 x 117.5 x 47.85mm (W x D x H) with fanned barebone while equipped with feature-rich IOs and ranged expansion slots to connect multiple industrial devices. It provides dual Gigabit LAN for Ethernet connectivity, diverse I/Os such as two USB3.2 Gen2 (Type-C), two USB3.2 Gen2 (Type-A), one USB2.0, one audio jack, along with great visual through dual displays with one HDMI 2.0b and one DP 1.4 up to 4096×2160@60Hz. There are two 260-pin SO-DIMM DDR4 3200MHz up to 32GB of memory and flexible expansion slots, including dual storages with one M.2 (Key M, 2242/2260/2280), one SATA 3.0, plus one M.2 (Key E, 2230) for Wi-Fi connectivity. Moreover, it provides a 19V/65W Power Adaptor and VESA mounting bracket for space-saving installation, and TPM for enhanced security. The NUC 6000 BOX Series is modestly designed to be perfect for home entertainment, office productivity, business, and embedded applications.
The fanless iBOX 6000 Series with model iBOX-J6412, based on Intel Celeron Processor J6412 (Elkhart Lake) and available optional models upon customer request, the iBOX-J6426, iBOX-X6211E, iBOX-X6413E, iBOX-X6425E, designed with Intel Pentium Processor J6426 and Intel Atom x6211E, x6413E, x6425E Processors for improved computing performance at the edge. The Series supports two 260-pin SO-DIMM DDR4 3200MHz up to 32GB of memory with In-Band ECC (iBOX-X6211E, iBOX-X6413E, iBOX-X6425E) for secured embedded usages. It provides dual Gigabit LAN for high-speed Ethernet connectivity, two USB3.2 Gen2 (Type-A), two USB3.2 Gen2 (Type-C), two USB2.0, as well as dual storages with one M.2 (Key M, 2242/2260/2280) and SATA 3.0, plus one M.2 (Key E, 2230) with PCIex1 and USB 2.0 for Wi-Fi to connect multiple industrial devices. The upgraded visual experience is ensured with two displays through one HDMI 2.0b and one DP 1.4, DP++ with maximum resolution up to 4096×2160@60Hz. Other key features include 19V/65W Power Adaptor, VESA mounting bracket, and TPM onboard, overall wrapping up the great package for a wide range of embedded, industrial, and Edge computing applications through ensured cybersecurity and longevity support.
The NUC 6000 Motherboard Series available models are NUC-N6210, NUC-J6412, NUC-N6415, NUC-J6426, powered by Intel Celeron Processors N6210, J6412, and Intel Pentium Processors N6415, J6426 (Elkhart Lake) give upgrades to its performance, graphics, and integration for IoT usage. The Series is designed for advanced computing capabilities and improved I/Os, including two 260-pin SO-DIMM DDR4 3200MHz up to 32GB of memory, and dual Gigabit LAN for solid connectivity, four USB 3.2 Gen2, four USB 2.0, and one COM (RS232/422/485). Great visual is provided through dual displays with one HDMI 2.0b and one DP 1.4 both holing maximum resolutions up to 4096×2160@60Hz. There are also flexible expansion slots: one M.2 Key M, 2242/2260/2280 with PCIex1 and SATA3 for SSD, one SATA 3.0, one M.2 Key E, 2230 for Wi-Fi. Moreover, the NUC 6000 Motherboard Series supports 12V~19V DC-in as well as onboard TPM for enhanced security.
